Description
Roof element for vertical air outlet, suitable for circular air duct made of spiral-edged tubes, with 13 × 13 mm protective mesh and drainage openings.
Material and finish
Material options:
- galvanized sheet metal
- stainless steel sheet metal INOX AISI 304
- stainless steel sheet metal INOX AISI 316L
At customer's request any colour from the RAL palette.
Dimensions
| Ø D (mm) | Ø D1 (mm) | H (mm) | H1 (mm) | Q (m³/h) | |
|---|---|---|---|---|---|
| 200 | 203 | 332 | 228 | 100 or custom | 1200 |
| 250 | 253 | 414 | 284 | 100 or custom | 1800 |
| 315 | 318 | 522 | 358 | 100 or custom | 2900 |
| 355 | 358 | 588 | 404 | 100 or custom | 3600 |
| 400 | 403 | 663 | 456 | 100 or custom | 4600 |
| 450 | 453 | 745 | 512 | 100 or custom | 5800 |
| 500 | 503 | 828 | 568 | 100 or custom | 7100 |
| 560 | 563 | 927 | 636 | 100 or custom | 8700 |
| 600 | 603 | 994 | 682 | 100 or custom | 10200 |
| 630 | 633 | 1043 | 716 | 100 or custom | 11300 |
| 710 | 713 | 1176 | 806 | 100 or custom | 14300 |
| 800 | 803 | 1325 | 910 | 100 or custom | 18100 |
| 900 | 903 | 1490 | 1022 | 100 or custom | 23000 |
Installation
Fitting to a pipe
Installation with flange to concrete floor
| Ø D (mm) | Ø B (mm) | a × b (mm) | Vijaki | Prirobnica Flange d × t (mm) |
|---|---|---|---|---|
| 160 | 205 | 7 × 12 | 6×M6 | 35 × 3 |
| 200 | 245 | 7 × 12 | 6×M6 | 35 × 3 |
| 250 | 295 | 7 × 12 | 6×M6 | 35 × 3 |
| 315 | 360 | 7 × 12 | 8×M6 | 35 × 3 |
| 350 | 395 | 7 × 12 | 8×M6 | 35 × 3 |
| 400 | 445 | 7 × 12 | 8×M6 | 35 × 3 |
| 500 | 555 | 9.5 × 14.5 | 12×M8 | 45 × 4 |
| 600 | 655 | 9.5 × 14.5 | 12×M8 | 45 × 4 |
| 700 | 755 | 9.5 × 14.5 | 12×M8 | 45 × 4 |
| 800 | 855 | 9.5 × 14.5 | 16×M8 | 45 × 4 |
| 900 | 955 | 9.5 × 14.5 | 16×M8 | 45 × 4 |
